ASMETAL Catalogue

PEUGEOT > 406 (19 Quantity)

	ASMETAL No	Product Description	Dimensions	Oem No
	10PE2000	Ball Joint	tp:M14x1.5 RHT cr:1/8 c:Ø15.9 tp2:M40x1.5 RHT / 0,34 kg	96 233 739, 95 028 039 (3) OEM
	11PE2500	Silentblock Bushing	di:Ø14 do:Ø45.05 / 0,3 kg	3640 35
	17MT1000	Tie Rod End Right	L:129.7 cr:1/10 c:Ø18.4 tp:M14x1.5 th:MM20x1.5 RHT / 0,64 kg	MC891911, MK309190 (3) OEM
	17MT1001	Tie Rod End Left	c:Ø18,4 th:MM20x1,5 LHT / 0,64 kg	MC891910, MK309189 (4) OEM
	17PE2500	Tie Rod End Left	L:120 cr:1/5 c:Ø11.8 tp:M10x1.25 th:MM16x1.5 RHT / 0,49 kg	3817 40
	17PE2501	Tie Rod End Right	L:120 cr:1/5 c:Ø11.8 tp:M10x1.25 th:MM16x1.5 RHT / 0,49 kg	3817 39
	20PE2500	Axial Joint	L:314.5 tp:M12x1 th:MM16x1.5 RHT / 0,66 kg	3812 A9
	20PE2501	Axial Joint	L:301 tp:M16x1.5 th:MM16x1.5 RHT / 0,83 kg	3812 C4, 3812 C3 (1) OEM
	26CT0200	Stabiliser Link	L:323 tp:M12x1.75 RHT / 0,51 kg	5087 40
	26PE2500	Stabiliser Link Rear	L:160 tp:M10x1.5 RHT / 0,26 kg	96 15 230 080, 5178 38
	26PE2501	Stabiliser Link Rear	L:245.5 tp:M12x1.25 RHT / 0,46 kg	96 287 831, 5178 39
	26PE2502	Stabiliser Link	L:320 tp:M12x1.5 RHT / 0,44 kg	96 177 836, 5087 43 (2) OEM
	26PE2505	Stabiliser Link Rear	L:160 tp:M10x1.5 RHT / 0,38 kg	96 152 300 80, 5178 38
	30PE2510 IN PREPARATION	Track Control Arm Left	4,76 kg	3520.C0, 3520.H1
	30PE2511 IN PREPARATION	Track Control Arm Right	4,76 kg	3521.80, 3521.E1
	38PE2500	Silentblock for TCA	L:83 di:Ø20 / 0,36 kg	3523 61
	38PE2501	Silentblock for TCA	L:38 di:Ø14.2 do:Ø47.5 / 0,15 kg	3523 60, 3523 78
	45PE2520	Suspension Support Buffer Front	di:Ø19 do: Ø53 L:110mm / 0,1 kg	5033 40
	45PE4500	Engine Mounting	th:MM10X1.5 RHT do:Ø83 / 0,73 kg	1844 77
